WKP102MCPEJ0KR單層陶瓷電容器Vishay
發布時間：2024-04-30 09:23:10 瀏覽：2377
WKP102MCPEJ0KR是Vishay生產的單層陶瓷電容器，適用于需要控制功率輸入并提供更低成本組件的電路設計。該電容器能夠承受760VAC|500VAC的電壓，并在最高工作溫度為125°C的環境下正常工作。此款高頻電容器采用徑向端接方式，深度為6mm(最大)，公差為20%，電容值為0.001uF。其引線直徑為0.8mm，間距為12.5mm。
具體特征包括：
- 電容器由兩面鍍銀的陶瓷盤組成
- 連接引線由直徑為0.6毫米或0.8毫米的鍍錫銅制成
- 電容器可提供直線或扭結引線，引線間距為10.0mm或12.5mm
- 涂層采用符合UL 94 V-0標準的藍色阻燃環氧樹脂
電容范圍：33pf ~ 4.7 nF
電容公差：±10%，±20%
額定電壓
?X1: 760 VAC, 50 Hz (IEC 60384-14)
760 VAC, 50 Hz / 60 Hz (US/UL/CSA 60384-14)
?Y1: 500 VAC, 50 Hz (IEC 60384-14)
500vac, 50hz / 60hz (US/UL/CSA 60384-14)
測試電壓
?4000vac, 50hz, 2s組件測試(100%)
?4000 VAC, 50 Hz, 60 s隨機抽樣測試(破壞性)
?4000vac, 50hz, 60s耐壓涂層(破壞性)
500vdc時的絕緣電阻：≥10000 MΩ(60秒)
耗散因子
第一類:最大0.5% (1khz)
第二類:最大2.5% (1khz)
此外，WKP102MCPEJ0KR陶瓷電容器符合IEC 60384-14標準，具有高可靠性，并提供多種不同的引線樣式。
該電容器的應用包括符合IEC 60384-14標準的X1、Y1類型應用，以及線對線濾波(X類)和線對地濾波(Y類)。
