Renesas微控制器和微處理器RL78 低功耗 8 位和 16 位 MCU

發布時間：2021-03-22 17:10:47 瀏覽：2150

Renesas微控制器和微處理器RL788/16位微控制器（MCU）進一步提高了電源效率，具備行業技術領先的低功耗性能指標。正常情況下工作時功能損耗為45.5μA/MHz，時鐘工作時功能損耗為0.57μA/MHz。內嵌高精度（±1%）高速片上振蕩器、可重寫100萬次的后臺管理操作數據閃存、溫度傳感器和多電源接口端口等功能有利于減少系統生產成本和重量。

深圳市立維創展科技有限公司，優勢代理分銷Renesas產品線，部分系列常備現貨。

詳情了解Renesas請點擊：/brand/59.html

或聯系我們的銷售工程師：0755-83642657 QQ: 2295048674

器件數量: 30	Bit Size	CPU	Program Memory (KB)	Data Flash (KB)	RAM (KB)	Lead Count (#)	Supply Voltage (V)
	16	RL78	24, 32, 48, 64, 96, 128, 256, 384, 512	8	2, 3, 4, 6, 8, 16, 20, 24	48, 64, 80, 100, 128	2.7 - 5.5
RL78/D1A
	16	RL78	8, 16, 24, 32, 48, 64	4	0.5, 1, 1.5, 2, 3, 4	20, 30, 32, 48, 64	1.8 - 5.5, 2.7 - 5.5
RL78/F12
	16	RL78	16, 32, 48, 64, 96, 128	4	1, 2, 3, 4, 6, 8	20, 30, 32, 48, 64, 80	2.7 - 5.5
RL78/F13
	16	RL78	48, 64, 96, 128, 192, 256	4, 8	4, 6, 8, 10, 16, 20	30, 32, 48, 64, 80, 100	2.7 - 5.5
RL78/F14
	16	RL78	128, 192, 256, 384, 512	8, 16	10, 16, 20, 26, 32	48, 64, 80, 100, 144	2.7 - 5.5
RL78/F15
	8	RL78	1, 2, 4	0	0.5, 0.25, 0.125	10, 16	2 - 5.5
RL78/G10
	16	RL78	16	2	1.5	10, 16, 20, 24, 25	1.6 - 5.5
RL78/G11
	16	RL78	2, 4, 8, 12, 16	0, 2	0.5, 0.25, 0.75, 1, 1.5, 2	20, 24, 30	1.8 - 5.5, 2.4 - 5.5
RL78/G12
	16	RL78	16, 32, 48, 64, 96, 128, 192, 256, 384, 512	0, 4, 8	2 ~ 32	20, 24, 25, 30, 32, 36, 40, 44, 48, 52, 64, 80, 100, 128	1.6 - 5.5, 2.4 - 5.5
RL78/G13
	16	RL78	8, 384, 512	8	24, 32	44, 48, 64, 100	1.6 - 5.5, 2.4 - 5.5
RL78/G13A
	16	RL78	16, 32, 48, 64, 96, 128, 192, 256, 384, 512	4, 8	2.5 ~ 48	30, 32, 36, 40, 44, 48, 52, 64, 80, 100	1.6 - 5.5
RL78/G14
	16	RL78	16, 32, 48, 64	4	2, 3, 4	25, 32, 48, 64	1.6 - 3.6, 2.4 - 3.6
RL78/G1A
	16	RL78	32	2	5.5	32, 48	2.4 - 5.5
RL78/G1C
	16	RL78	128, 192, 256	8	12, 16, 20	48	1.6 - 3.6
RL78/G1D
	16	RL78	32, 64	4	5.5	24, 32, 36, 48, 64	1.6 - 5.5
RL78/G1F
	16	RL78	8, 16	0	1.5	30, 32, 44	2.7 - 5.5
RL78/G1G
	16	RL78	256, 384, 512	8	24, 32, 48	64	1.8 - 3.6
RL78/G1H
	8	RL78	8	0	1	20	2 - 5.5
RL78/G1M
	8	RL78	8	0	1	20	2 - 5.5
RL78/G1N
	16	RL78	2, 16	2	1.5	24, 32	2.7 - 3.6
RL78/G1P
	16	RL78	64, 96, 128	4	5.5, 8	48, 64, 80	1.8 - 5.5, 2.4 - 5.5
RL78/H1D
	16	RL78	32, 64	4	2, 4	20, 30, 38	2.7 - 5.5
RL78/I1A
	16	RL78	64, 128	0	6, 8	80, 100	1.9 - 5.5
RL78/I1B
	16	RL78	64, 128, 256, 512	2	6, 8, 16, 32	64, 80, 100	1.6 - 5.5, 1.7 - 5.5
RL78/I1C
	16	RL78	8, 16, 32	2	0.7, 2, 3	20, 24, 30, 32, 48	1.6 - 3.6
RL78/I1D
	16	RL78	32	4	8	32, 36	2.4 - 5.5
RL78/I1E
	16	RL78	8, 16, 32	2	1, 1.5	32, 44, 48, 52, 64	1.6 - 5.5
RL78/L12
	16	RL78	16, 32, 48, 64, 96, 128	4	1, 1.5, 2, 4, 6, 8	64, 80	1.6 - 5.5
RL78/L13
	16	RL78	48, 64, 96, 128	8	5.5	80, 100	1.8 - 3.6
RL78/L1A
	16	RL78	64, 96, 128, 192, 256	8	8, 10, 12, 16	80, 85, 100	1.6 - 3.6
RL78/L1C
